ENORM 10 lifting accessories are characterised by their high strength alongside increased toughness and an above average resistance to extreme temperatures. ENORM 10 products meet the requirements of the PAS 1061

For chain slings EN 818-4 and suitable for all clevis heads of JDT-Assembling-System

  • Marking: According to standard
  • Temperature range: - 40°C to 200° C 100 %, 200° C to 300° C 90 %, 300° C to 400°C 75 %
  • Standard: EN 1677-1
  • Safety factor: 4:1
  • Grade: 10
Select a row from the table below, then click the add to quote button
Part Code Code WLL
ton
a1
mm
a2
mm
b
mm
Ø d1
mm
Ø d2
mm
t
mm
Weight
kg
LEIK6SH ENORM WGÖ 6 1,4 20 36 6 36 7,7 51 0,26
LEIK8SH ENORM WGÖ 8 2,5 26 43 8 41 10,6 56 0,41
LEIK10SH ENORM WGÖ 10 4 35 52 10 51 13,2 73 0,86
LEIK13SH ENORM WGÖ 13 6,7 43 65 13 59 17 88 1,51
