Small aluminium multi driven chain hoists with a wide range of lifting applications. Can be used with a drill machine. The drill can be connected with 1.5-3 mtr long operating cable in the hoist, so the load can be easily lifted and lowered with the help of the drill machine.
Can also be used directly from the shaft (8 mm hexagonal) coming out of the side of the hoist frame, either with a drill or manually with a comb or 1/2" ratchet handle. The lifting and lowering speed is directly dependent on the rotation speed of the drill, so the speed is always controlled by the drill's own controls.
The standard lifting height is 3 mtr. Other lifting heights can be supplied quickly. The upper and lower hooks are equipped with a swivel.
Especially suitable for
- Installation and maintenance work
- Workshops and repair facilities
- Construction sites
- Applications where lifting is carried out using a power drill
Product features
- Operated using a standard power drill
- The power drill is connected to the hoist via a 1.5 m control cable
- Can also be operated directly from the 8 mm hexagonal drive shaft using a power drill, hand crank, or 1/2" ratchet handle
- Lifting and lowering speed is determined by the rotational speed of the power drill
- Standard lifting height: 3 m
- Also available with other lifting heights
- Top and bottom hooks are equipped with swivel hooks
- Material: Aluminium | CR6+ free
- Marking: CE-marked
- Temperature range: -10 - (+) 50°C
- Finish: Painted, white/orange
- Note: Also available 3 m length operating cable
SPARE PARTS
| Spare part (product code) | Description | Suitable for hoist (product code) |
| KTP250YKO | Top hook ass'y | Part no. 22 | KTP250 |
| KTP250AKO | Bottom hook ass'y | Part no. 40 | KTP250 |
| KTP250SAL | Hook latch kit | Incl. parts for one hook | KTP250 |
| KTP250JAR | Friction disc set (2 pcs) | Part no. 13 | KTP250 |
| KTP250RAT | Ratchet wheel | Part no. 14 | KTP250 |
| KTP500YKO | Top hook ass'y | Part no. 22 | KTP500 |
| KTP500AKO | Bottom hook ass'y | Part no. 40 | KTP500 |
| KTP500SAL | Hook latch kit | Incl. parts for one hook | KTP500 |
| KTP500JAR | Friction disc set (2 pcs) | Part no. 13 | KTP500 |
| KTP500RAT | Ratchet wheel | Part no. 14 | KTP500 |
| KTP1000YKO | Top hook ass'y | Part no. 22 | KTP1000 |
| KTP1000AKO | Bottom hook ass'y | Part no. 40 | KTP1000 |
| KTP1000SAL | Hook latch kit | Incl. parts for one hook | KTP1000 |
| KTP1000JAR | Friction disc set (2 pcs) | Part no. 13 | KTP1000 |
| KTP1000RAT | Ratchet wheel | Part no. 14 | KTP1000 |
| KTPKAAPELI1,5 | 1,5 m operating cable, "standard" | Part no. 2 | KTP250, KTP500, KTP1000 |
| KTPKAAPELI3 | 3,0 m operating cable, "long" | Part no. 2 | KTP250, KTP500, KTP1000 |
| TALKE329G100 | Hoist chain 3,2 × 9 mm | Grade 100, EN 818-7 | Part no. 39 | KTP250 |
| TALKE4312G100 | Hoist chain 4,3 × 12 mm | Grade 100, EN 818-7 | Part no. 39 | KTP500, KTP1000 |
Also other spare parts available with a delivery time, ask our sales for more information.
