Gunnebo Industries





  • Material: Quenched and tempered alloy steel grade 10.
  • Marking: Code and grade.
  • Finish: Painted.
  • Warning: Not to be heat treated.
  • Safety factor: 4:1
  • Grade: 10
Select a row from the table below, then click the add to quote button
Part Code Code WLL
ton
L
mm
B
mm
C
mm
E
mm
A
mm
H
mm
G
mm
Weight
kg
SALKAKL1078LKNK LKNK-7/8-10 2.6 154 28 28 38 12 24 18 0.9
SALKAKL1010LKNK LKNK-10-10 4 191 35 35 44 15 31 23 1.56
SALKAKL1013LKNK LKNK-13-10 6.8 236 40 45 48 19 38 28 3.19
SALKAKL1016LKNK LKNK-16-10 10.3 293 53 62 61 25 43 34 5.33
SALKAKL1022LKNK LKNK-22-10 20 400 74 80 80 35 43 67 15.11
