Gunnebo Industries




WARNING! Not to be heat treated.

  • Material: Quenched and tempered alloy steel grade 10.
  • Marking: Code and grade.
  • Finish: Painted.
  • Safety factor: 4:1.
  • Grade: 10
Select a row from the table below, then click the add to quote button
Part Code Code WLL
t
L
mm
B
mm
C
mm
E
mm
A
mm
G
mm
H
mm
Weight
kg
SALKAL1078LNK LKN-7/8-10 2,50 155 28 28 38 12 18 24 0.83
SALKAL1010LNK LKN-10-10 4,00 192 35 37 44 15 23 31 1.5
SALKAL1013LNK LKN-13-10 6,70 238 40 47 48 19 28 38 3
SALKAL1016LNK LKN-16-10 10,00 295 53 65 61 25 34 43 5.06
