General: Specially rugged profile chain in grade 12 for lifting.
- Material: Alloy steel grade 12
- Marking: Every link is marked with manufactor ID and grade.
- Temperature range: -40ºC to 200ºC
- Finish: Painted.
- Note: Not to be heat-treated.
- Grade: 12
Select a row from the table below, then click the add to quote button
|
Safety factor
|
1-leg chains
|
|
2-leg chains
|
|
|
|
3- and 4-leg chains
|
|
|||||||
|
4
|
 |
 |
 |
|
 |
|
 |
|
|||||||
|
angle of inclination
|
-
|
-
|
up to 45°
|
45°-60°
|
up to 45°
|
45°-60°
|
up to 45°
|
45°-60°
|
|||||||
|
load factor
|
1
|
0.8
|
1.4
|
1
|
1.12
|
0.8
|
2.1
|
1.5
|
|||||||
|
Ø
|
load capacity [kg]
|
|
|
|
|
|
|
|
|||||||
|
7
|
2,360
|
1,900
|
3,350
|
2,360
|
2,650
|
1,900
|
5,000
|
3,550
|
|||||||
|
8
|
3,000
|
2,360
|
4,250
|
3,000
|
3,350
|
2,360
|
6,300
|
4,500
|
|||||||
|
10
|
5,000
|
4,000
|
7,100
|
5,000
|
5,600
|
4,000
|
10,600
|
7,500
|
|||||||
|
13
|
8,000
|
6,300
|
11,200
|
8,000
|
9,000
|
6,300
|
17,000
|
11,800
|
|||||||
|
16
|
12,200
|
9,700
|
17,000
|
12,200
|
13,600
|
9,700
|
25,600
|
18,300
|
|||||||
