Open Wedge Socket With Safety Bolt G-6423

The Green Pin® Open Wedge Socket BN is an open wedge socket with a safety bolt. The socket offers a double safety (split pin and safety bolt) which prevents accidental unscrewing of the pin. The socket is made from high tensile steel, while galvanization ensures its long-term durability. The Green Pin® Open Wedge Socket BN is available for wire rope with a diameter from 7-8 up to 40-42 mm.

  • Material: high tensile steel
  • Marking: According to standard, CE-marked
  • Temperature range: -40°C up to +200°C
  • Finish: hot dipped galvanized
  • Standard: EN 13411-6
